Opel Astra H Kenwood Apple Android Speaker Upgrade

Enhance your Opel Astra H with our Kenwood Apple CarPlay and Android Auto speaker upgrade, providing superior sound quality for both the front and rear areas. This upgrade includes high-quality Hertz DSK.165.3 2-way system speakers for the front and Hertz DCX165 coaxial speakers for the rear, all powered by the advanced features of the Kenwood double-DIN DMX5020BTS.

Kenwood DMX5020BTS 2DIN Radio with Apple CarPlay and Android Auto

With the Kenwood DMX5020BTS double DIN car stereo, you can enjoy the benefits of smartphone integration with your vehicle, while optimizing sound quality through Kenwood’s DSP function, time alignment, and a 13-band equalizer.

Opel Astra H (2004–2010)

The Opel Astra H, produced from 2004 to 2010, is available in various body styles including hatchback, sedan, station wagon, and convertible. The factory-installed woofers are located in the front door panels, with tweeters mounted in the mirror triangles. The rear doors house additional woofers behind the door panels.

Suitable for Opel Astra H (2004–2010)

Package Contents:

• 1 x 2DIN Kenwood DMX5020BTS Car Radio with Apple CarPlay and Android Auto:
  • No gray import, service, and support through Kenwood Austria.
• 1 x Hertz DSK 165.3 2-Way System (Pair) for Front Doors:
  • 165mm woofers with external tweeters.
• 1 x Hertz DCX 165 Coaxial Speakers (Pair) for Rear Installations:
  • 165mm coaxial speakers.
• 4 x Mounting Rings for Front and Rear Doors: Ensure stable and secure installation.
• 4 x Speaker Adapter Cables and Crimp Connectors for Doors: For easy integration with the existing audio system.
• 1 x Plastic Lever Tool: For removing door panels and dashboard components without damage.
• 1 x Pack of 8 Sound Deadening Sheets: Reduces vibrations and enhances sound quality.
• 1 x Wiring Adapter for Kenwood: Connects the car’s existing wiring harness to the Kenwood radio.
• 1 x Antenna Adapter for Kenwood: Ensures compatibility between the car’s antenna and the new radio.
• 1 x Double DIN Radio Bracket for Dashboard: Provides a secure fit for the Kenwood radio.

This sound system upgrade is ideal for vehicle owners and installers confident in removing door panels and the factory radio.

Kenwood DMX5020BTS Technical Details in Brief:

• High-Resolution WVGA Double-DIN Monitor: 17.3 cm (6.8″) capacitive high-gloss touch panel.
• Responsive Control: User-friendly interface with menu displays in 14 languages; white key illumination.
• UKW RDS-Tuner with 24 Presets: Only 75mm installation depth (no CD/DVD drive).
• CarPlay & Android Auto via USB; Android USB Mirroring: Spotify control via CarPlay and Android Auto.
• iPod/iPhone Control via USB with up to 1.5A Charging Current: DSP with time alignment and 13-band equalizer.
• Output Power: 4 x 50 Watts.
• Three Preamp Outputs (2V): Front, rear, and sub.
• Bluetooth for Hands-Free Calling (HFP 1.6) and Audio Streaming (A2DP/AVRCP1.5): Compatible with all current smartphones.
• Rear USB Port for Audio and Video: Supports MPEG1/2/4, H.264, MKV, WMV, JPEG, AAC, FLAC (192kHz/24bit), MP3, WAV & WMA.
• Rear Camera Input with Adjustable Parking Guidelines: 3.5mm jack AV input, Cinch video output, hands-free microphone input, prepared for steering wheel remote control.

Installation Tips

1. Prepare Your Workspace: Gather necessary tools such as screwdrivers, panel removal tools, crimping tools, and electrical tape.
2. Remove Door Panels: Use the plastic lever tool to carefully remove door panels, accessing factory-installed speakers.
3. Install Front Speakers: Mount the Hertz DSK 165.3 speakers using provided mounting rings. Connect speaker adapter cables to the existing wiring harness.
4. Install Tweeters: Replace factory tweeters with new ones, ensuring proper crossover connection.
5. Add Sound Insulation: Apply sound deadening sheets to doors to reduce vibrations and improve sound quality.
6. Install Rear Coaxial Speakers: Mount Hertz DCX 165 coaxial speakers in rear doors using mounting rings and connect adapter cables.
7. Install Kenwood Radio: Fit Kenwood DMX5020BTS into the dashboard using the double DIN bracket, connect wiring and antenna adapters, and secure all connections.
8. Test the System: Verify that all speakers and the radio function correctly. Adjust DSP settings and the 13-band equalizer for optimal sound.

Benefits of Upgrading Your Car Audio System

Upgrading your car’s audio system offers numerous benefits, including improved sound quality, greater clarity, and enhanced bass response. A more balanced soundstage contributes to a more enjoyable listening experience. High-quality components ensure durability and longevity, providing you with a reliable audio solution for years to come. Enhanced audio systems also increase the overall value of your vehicle and can make daily commutes or long drives more pleasurable. Custom audio setups allow for personalized sound preferences, catering to individual listening styles and genres.

Secure and Convenient Shopping Experience

At Auto-Lautsprecher.eu, we prioritize the safety and convenience of our customers. We offer secure payment options like Klarna and EPS transfer, ensuring that your transactions are safe and hassle-free. Our detailed installation guides and support ensure that you can easily set up your new audio system, even if you’re not an expert. Our commitment to customer satisfaction is reflected in our high-quality products and excellent customer service. Whether you’re looking for a simple upgrade or a complete audio overhaul, we provide the tools and expertise you need to achieve the best possible sound in your vehicle.

For more information on our products and services, visit hervorragende Auto Lautsprecher. Additionally, you can find useful tips and step-by-step instructions for various car models on our Auto Lautsprecher Einbautipps page. These resources will help ensure that your installation process is smooth and successful, providing you with the best possible audio experience in your vehicle.

With this comprehensive upgrade package, you’ll transform your Opel Astra H’s audio system, ensuring an exceptional listening experience every time you drive. Enjoy superior sound quality and professional installation with products from Auto-Lautsprecher.eu, your trusted partner for car audio solutions.
